Acrylic Stainless Light boxes

Acrylic & Stainless Steel Blade Light Box Sign

This type of blade light box sign combines stainless steel structure with acrylic illuminated panels, delivering a clean and modern visual effect for premium storefront signage.

Material & Structure

The structure is built with stainless steel frame to ensure durability and stability.

• Material: stainless steel 201 / 304 / 316 optional
• Thickness: 1.2mm–2.0mm stainless steel
• Structure: laser cutting + bending + welding
• Internal reinforcement: steel frame

Panel & Illumination Surface

• Panel material: acrylic (PMMA)
• Thickness: 3mm–5mm
• Light transmission: high transparency for clear illumination
• Graphics: UV printing / vinyl / engraved graphics
• Display: double-sided illuminated

Lighting System

• LED type: high brightness LED modules
• Waterproof rating: IP65 / IP67
• Power supply: Mean Well or equivalent
• Voltage: DC 12V / 24V
• Lighting: uniform and soft illumination

Surface Finish

• Stainless steel finish: brushed / mirror / painted
• Anti-corrosion and UV resistant
• Outdoor durability: 5–8 years or longer

Installation

• Wall-mounted bracket installation
• Reinforced projecting arm
• Hidden wiring system

Key Features

• Clean and modern appearance
• High light transmission effect
• Double-sided visibility
• Strong structural stability
• Suitable for premium branding

Applications

• Cafe signage
• Restaurant signage
• Retail storefronts
• Commercial street signage
• Brand identity signage
