Wayfinding & Directional signages

Outdoor Post & Arm Directional Wayfinding Sign

Post and arm directional signage is widely used in outdoor environments such as parks, commercial areas, and campuses, providing clear directional information with high visibility.

Material & Structure

The structure is designed with a strong steel frame to ensure stability and wind resistance.

• Main post: galvanized steel or aluminum column
• Arm structure: steel or aluminum arm with reinforced connection
• Panel material: aluminum plate (2.5mm–3.0mm) or stainless steel (1.2mm–2.0mm)
• Structure process: laser cutting + bending + welding
• Internal reinforcement for structural strength

Surface & Graphics

• Surface finish: powder coating / fluorocarbon coating
• Graphics: UV printing / screen printing / vinyl
• Color: customizable according to project

Lighting System (Optional)

• LED type: high brightness LED modules
• Waterproof rating: IP65 / IP67
• Power supply: Mean Well or equivalent
• Voltage: DC 12V / 24V

Durability

• UV resistant and anti-corrosion
• Wind-resistant structure design
• Suitable for outdoor environments
• Service life: 5–10 years

Installation

• Ground-mounted with embedded foundation
• Anchor bolts fixing system
• Reinforced base plate design

Key Features

• Clear directional guidance
• Strong structural stability
• Suitable for outdoor environments
• Modular arm configuration
• Custom design available

Applications

• Parks and public spaces
• Commercial streets
• Campus navigation
• Tourist areas
• Industrial parks
